1KG/bottle、30ML/branch

1、Single-component packaging, easy to use; high-pressure mercury lamp curing is required, and the curing speed is fast.

2、The glue is light yellow or blue, which is convenient for construction and dispensing.

3、This product has strong adhesion to both glass and metal pins.

4、This product has strong resistance to water vapor, mold, and salt spray, and can protect the metal pins and ITO conductive electrodes from being eroded by external water vapor ions.

The pins of the circuit board or liquid crystal panel are bonded and covered with ITO glass, and the electronic cable is bonded and fixed with the ACF tape.

Viscosity（25℃）

5000-10000 cPa.sadjustable

refractive index（nd²⁰）

1.47-1.50

25℃density（g/ml）

0.98-1.00

Electronic lead glue

Shear strength

15（MPa）

curing energy

200MJ/CM²

Curing depth

2mm

solid content

100%（Solvent-free, green and environmentally friendly）

After curing

light yellow or light green

Operating temperature

-40~100℃
